A9F74225 SCHNEIDER Filter Modules In Stock

Product Details

The Schneider A9F74116 is a low-voltage miniature circuit breaker (MCB) part of the Acti9 iC60N series. It is designed to protect electrical circuits against short circuits and overload currents. The A9F74116 has a 1P configuration, meaning it has one protected pole, and a rated current of 16A. It has a C tripping curve, which means it is designed to trip quickly in response to high currents, but with some delay to accommodate inrush currents from motors and other inductive loads.

Product Features

• Rated current: 16A

• Tripping curve: C

• Breaking capacity: 10kA at 220VAC to 240VAC, 6kA at 230VAC

• Standards compliance: EN/IEC 60898-1, EN/IEC 60947-2

• Degree of protection: IP20 (enclosure), IP40 (enclosed)

• Operating temperature: -35°C to 70°C

• Storage temperature: -40°C to 85°C

• Mechanical durability: 20,000 cycles

• Electrical durability: 10,000 cycles

• Terminal connections: Single terminal (top or bottom) 1…25 mm² rigid, single terminal (top or bottom) 1…16 mm² flexible

Product Benefits

• Protects against short circuits and overload currents

• Compact design saves space in panels

• Easy to install and operate

• Reliable and long-lasting

• Wide range of applications

Applications

The Schneider A9F74116 MCB is suitable for a wide range of applications, including:

• Residential buildings

• Commercial buildings

• Industrial facilities

• Machine control panels

• HVAC systems

• Lighting circuits

Considerations

• The A9F74116 MCB should be installed by a qualified electrician.

• The MCB should be used in conjunction with appropriate overcurrent protection devices, such as fuses or relays.

• The MCB should not be overloaded.

• The MCB should not be used in hazardous environments.

Conclusion

The Schneider A9F74116 is a versatile and reliable MCB that can be used to protect a wide range of electrical circuits. It is a good choice for applications where space is limited and ease of installation is important.

Additional Resources

Product details:

A9F74225 SCHNEIDER Filter Modules
