REXROTH HCS21E-W0012-A-03-NNNN

REXROTH HCS21E-W0012-A-03-NNNN  Servo drive controller

Product information：

Brand：REXROTH                           Model number：HCS21E-W0012-A-03-NNNN

Lead Time：3-day working da        Country of origin: Germany

Price: Please contact us                   Product weight：0.56kg

HS: 8517623990

Product technial information：

In devices of the order code "-L***", the internal fan of the cooling system is

controlled depending on the temperature of the cooling system. As the load

increases, the temperature at the heat sink rises and thereby the sound pres‐

sure level according to the characteristic below. The specified "average

sound pressure level LP" applies to operation under rated conditions.

Also depending on firmware and control section; see parame‐

ter description "P-0-0001, Switching frequency of the power

output stage"; see "P-0-4058, Amplifier type data"; for supply

units the switching frequency is 4.2 kHz

 Plus dissipation of braking resistor and control section; find in‐

terim values by interpolation to P_Diss_cont

 Plus dissipation of braking resistor and control section

 See fig. "Air intake and air outlet at device"

Tab. 5-6: HCS - Data for cooling and power dissipation

bserve the indicated minimum distances!

Above the devices there may only be such materials which

● are not combustible

The figure below illustrates the connection between power dissipation and

output current, depending on the switching frequency fs

 which was set at the

drive controller. See also Parameter Description "P-0-0001, Switching fre‐

quency of the power output stage".

This section contains

● Data for control voltage supply

● Data for mains voltage supply

● Data of DC bus

● Data of integrated braking resistor and requirements on an external

braking resistor

● Data of inverter

● Data for cooling and power dissipation
