  • SC656A-BV0FP Hyde Park    Wiring Connector

SC656A-BV0FP Hyde Park Wiring Connector

PRODUCT DETAIL

SC656A-BV0FP Hyde Park    Wiring Connector


Product information:

Brand:Hyde Park                             Model number:SC656A-BV0FP

Condition:new                              Warranty: 12 month

Lead Time:3-day working da        Country of origin: Britain

Price: Please contact us                   Product weight:0.065kg

HS: 8517623990


Product technial information:



Power Supply:


 Supply: + 15 to 24 VDC @ 50 mA max

 Protection: ESD and reverse-polarity


Analog Output:


 Output Voltage: 0 Volt (minimum) to 10 Volts (maximum)

 Output Resolution: 9.77 mV (millivolts)

 Output Load: 1000 ohms (minimum)

 Protection: Short-circuit to common and ESD


Operating Temperature:


 @ 15 VDC supply 0 to 60C (32F to 140F) @ 100% relative humidity

 @ 24 VDC supply 0 to 50C (32F to 122F) @ 100% relative humidity


Sensing:


 Maximum far limit: 254.0 mm (10.00 in.)

 Resolution, object position, worst case:  0.69 mm (0.027 in.)

 Repeatability (Constant Temperature):  0.69 mm (0.027 in.)

 Minimum object area, flat smooth: 40 mm2

 (0.027 in.) @ 152 mm (6.0 in.) distance

 Minimum object diameter: 1.6 mm (0.06 in.) @ 152 mm (6.0 in.) distance

 Maximum plane-reflector angle:  10

 Sonic Cone Angle: 7


Sensor Dimensions: 74.00 mm(2.913) x 30.00 mm(1.182) x 16.25mm(.640)


Sensor Cable: Model No. AC130 - Straight Cable, 5 meters (16 ft.)

 (Must be purchased separately)


Sensor Materials:


 Housing: PEI

 Transducer face: FDA approved silicone rubber

 Cable: Non-toxic PVC jacket

 LED: Polycarbonate


Sensor Environmental Ratings:


NEMA 4X (Indoor Use Only) 5, 12, 12K, 13, and IP67


 Installation/Overvoltage Category: II



 CE Mark Compliant: Declaration of conformity available upon request.

This Product is UL Listed if powered by a Class II Power Supply and protected by a 2.0A Max UL Listed Fuse






Delivery information:

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Transport: In Stock Ready for Shipment via DHL, TNT, FEDEX, UPS, ARAMEX and etc

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!  We Can transport to the world!!!



Contact information:

Contact person:Luna Chen

Email Address::sales6@saulplc.com

WhatApp: +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.
