Fluke 700P29

Fluke 700P29 Pressure Module

Product information：

Brand：FLUKE              Model number：700P29

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.39KG

Product technial information：

Fluke 700P29 Gauge Pressure Module

The Fluke 700P29 Gauge Pressure Module is a versatile and accurate pressure measurement tool that is designed for use with Fluke 700 Series Process Calibrators. It offers a wide range of features that make it ideal for a variety of applications, including:

• Pneumatic pressure measurement: The Fluke 700P29 can measure gauge pressure up to 3000 psi (20.7 MPa) with an accuracy of 0.08% of full scale.

• Temperature compensation: The module features internal temperature compensation to ensure accurate readings over a wide temperature range (-10°C to 50°C).

• Multiple pressure units: The Fluke 700P29 can display pressure readings in any of 10 different pressure units, making it easy to use for a variety of applications.

• Rugged design: The module is housed in a rugged urethane molded case that protects it from rough handling and harsh conditions.

• Easy calibration: The Fluke 700P29 can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source.

Product Specifications

• Range: 3000 psi (20.7 MPa)

• Accuracy: 0.08% of full scale

• Resolution: 0.1 psi (0.001 MPa)

• Reference uncertainty (23 ± 3°C): 0.050%

• Total uncertainty 1 year: 0.080%

• Temperature range: -10°C to 50°C

• Pressure units: psi, kPa, MPa, bar, mmHg, inHg, mH2O, ftH2O, atm, Torr

• Media compatibility: Dry air or non-corrosive gas

• Electrical connection: Mini DIN connector

• Dimensions: 3.5 x 2.8 x 1.3 inches (90 x 71 x 33 mm)

• Weight: 10 ounces (283 grams)

Product Advantages

• Wide measurement range: The Fluke 700P29 can measure gauge pressure up to 3000 psi (20.7 MPa), making it suitable for a wide variety of applications.

• High accuracy: The module offers an accuracy of 0.08% of full scale, ensuring reliable and precise measurements.

• Temperature compensation: Internal temperature compensation ensures accurate readings even in fluctuating temperature environments.

• Versatile pressure units: The ability to display pressure readings in 10 different units makes the Fluke 700P29 suitable for global use.

• Rugged and durable: The rugged urethane molded case protects the module from harsh conditions and extends its lifespan.

• Easy calibration: Local calibration using the Fluke 700PCK Pressure Calibration Kit simplifies maintenance and reduces downtime.

Considerations

• Media compatibility: The Fluke 700P29 is compatible with dry air or non-corrosive gas only. Do not use the module with corrosive media.

• Pressure range: The module's maximum pressure range is 3000 psi (20.7 MPa). Do not exceed the specified pressure range to avoid damage to the module.

• Temperature range: The module operates within a temperature range of -10°C to 50°C. Do not use the module outside of this temperature range.

Product Applications

• Pneumatic pressure measurement: The Fluke 700P29 is ideal for measuring the pressure of pneumatic systems, such as air compressors, hydraulic presses, and HVAC systems.

• Pressure transducer calibration: The module can be used to calibrate pressure transducers, ensuring the accuracy of pressure measurements in various applications.

• Differential pressure measurement: The Fluke 700P29 can be used with a second pressure module to measure differential pressure, which is the difference in pressure between two points.

• Leak testing: The module can be used to detect leaks in pneumatic systems by measuring the pressure decay over time.

• Vacuum measurement: The Fluke 700P29 can be used to measure vacuum pressure by connecting it to a vacuum pump.

Overall, the Fluke 700P29 Gauge Pressure Module is a versatile and reliable tool that is well-suited for a wide variety of pressure measurement applications. Its high accuracy, wide measurement range, and rugged design make it a valuable asset for any technician or engineer who works with pneumatic systems.
