Automation Direct F2-04AD-1

Automation Direct F2-04AD-1  Input Module

Product information：

Brand：AUTOMATION DIRECT              Model number：F2-04AD-1

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.09KG

Product technial information：

Automation Direct F2-04AD-1: Product Details, Specifications, Advantages, Considerations, and Applications

Product Overview

The Automation Direct F2-04AD-1 is a 4-channel analog input module designed for use with DirectLOGIC DL205 series PLCs. It provides high-precision, isolated analog-to-digital conversion of 4-20mA current signals, making it ideal for a wide range of industrial applications.

Product Specifications

• Number of channels: 4

• Input type: Current

• Input range: 4-20mA

• Resolution: 12 bits

• Accuracy: ±0.1% of full scale

• Update rate: 2.5 ms per channel

• Input impedance: 250 ohms per channel

• Isolation voltage: 2500V RMS

• Power supply: 24VDC (user-supplied)

• Operating temperature: -40 to 85°C

• Dimensions: 4.0" x 1.0" x 3.0" (10.2 cm x 2.5 cm x 7.6 cm)

• Weight: 0.3 lbs (0.1 kg)

Product Advantages

• High precision and accuracy: The F2-04AD-1 provides high-precision, 12-bit analog-to-digital conversion with ±0.1% of full scale accuracy, ensuring reliable and accurate measurement of analog signals.

• Isolated inputs: The module's isolated inputs protect the PLC from damage caused by ground faults and electrical noise, ensuring reliable operation in harsh industrial environments.

• Fast update rate: The F2-04AD-1 offers a fast update rate of 2.5 ms per channel, enabling real-time monitoring and control of analog processes.

• Easy installation and maintenance: The module features a removable terminal block for easy wiring and a compact design for space-saving installation.

Considerations

• Power supply: The F2-04AD-1 requires a 24VDC power supply, which must be provided by the user.

• Input impedance: The module provides 250 ohms of input impedance per channel. If the transmitter being used requires a load resistance below 250 ohms, a resistor will need to be added in series with the input.

Product Applications

• Temperature measurement: The F2-04AD-1 can be used to measure temperature using 4-20mA current loop transmitters.

• Pressure measurement: The module can be used to measure pressure using 4-20mA current loop transmitters.

• Flow measurement: The F2-04AD-1 can be used to measure flow rate using 4-20mA current loop transmitters.

• Level measurement: The module can be used to measure liquid or solid level using 4-20mA current loop transmitters.

• Any application requiring high-precision, isolated measurement of 4-20mA current signals

Overall, the Automation Direct F2-04AD-1 is a versatile and reliable analog input module that offers a wide range of features and benefits for industrial applications.
