E53A4A1N DANAHER  Controller

E53A4A1N DANAHER  Controller

Product information：

Brand：DANAHER                          Model number：E53A4A1N

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.56kg

HS: 8517623990

Product technial information：

• 1/2 inch Graphic Dot Matrix Backlit LCD With Multiple

Language Capabilities

• Menu-Guided Operation

• Simple Interactive Diagnostics

• Password-Protected Access

• Universal Mounted, Epoxy Coated Aluminum 1/2 DIN,

NEMA 4X Enclosure

• (2) 0/4-20 mA Outputs and (4) Relays

The Model 53 Controllers are best suited for applications requiring

environmental ratings, high level of control, and multiple 0/4-20 mA

and relay outputs. The Model 53 features a easy to follow clear text

driven menu and is equipped with four electromechanical relays;

SPDT (Form C) contacts; UL rated 5A 115/230 Vac, 5A @ 30 Vdc

resistive. The controllers are housed in a 1/2 DIN, NEMA 4X

enclosure and include hardware for panel, surface or pipe mounting.

Ambient Conditions

Operational: -4 to 140ºF (-20 to 60ºC);

0 to 95% relative humidity, non-condensing

Storage: -22 to 158ºF (-30 to 70ºC);

0 to 95% relative humidity, non-condensing

Power Requirements

90-130 Vac, 50/60 Hz. (10 VA max.)

or 180-260 Vac, 50/60 Hz. (10 VA max)

Display

Graphic dot matrix LCD, 128 x 64 pixels with

LED backlighting; 1/2 inch (13 mm) main

character height; 1/8 inch (3 mm) auxiliary

information character height; menu screens

contain up to six text lines

Outputs

Two isolated 0/4 – 20 mA outputs; each with

0.004 mA (12 bit) resolution and drive capability

of 600Ω load

Control

High/low phasing, setpoint, deadband,

overfeed timer, off/on delay

Alarms

Low/high alarm point and low/high alarm point

deadband, off/on delay

Communication (Optional)

HART Protocol: Configure and measure data

for multiple analyzers using HART enabled

data system or hardware

Memory Backup (non-volatile)

All user settings are retained indefinitely in

memory (EEPROM)

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.
