SCXI-1120D National Instruments Analog Input Module

SCXI-1120D National Instruments Analog Input Module

Product information：

Brand：National Instruments                             Model number：SCXI-1120D

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.665kg

HS: 8517623990

Product technial information：

When using a single chassis, leave W42 and W43 in position 1 on the

SCXI-1120/D that is connected to the DAQ device. In this setting, the

module drives MISO to SERDATOUT and connects the necessary pullup

resistor to the SERDATOUT line.

When using multiple chassis cabled to your DAQ device with shielded

cables, leave jumper W42 and W43 in position 1 on the SCXI-1120/D

modules that are connected to the DAQ device. In this setting, the module

drives MISO to SERDATOUT and connects the necessary pullup resistor

to the SERDATOUT line. All of the shielded adapters buffer and combine

the SERDATOUT from each chassis to the DAQ device.

When using multiple chassis cabled to your DAQ device with ribbon

cables, leave jumper W43 in position 1 on all of the SCXI-1120/D modules

that are cabled to the DAQ device. Set jumper W42 to position 1 on only

one of the SCXI-1120/D modules cabled to the DAQ device. All the other

SCXI-1120/D modules that are cabled to the DAQ device should have

jumper W42 in position 3. If too many pullup resistors are attached to the

SERDATOUT line, the drivers cannot drive the line low. See Table 2-1 for

the description and configuration of the jumper settings.
