PO972VA FOXBORO Power module

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

PO972VA  FOXBORO Power module In Stock

1. Turn off transmitter power source.

2. Remove the Field Terminals and the Electronics compartment covers by rotating them

counterclockwise. Screw in cover lock if applicable.

3. Remove the digital display (if applicable) as follows: grasp the two tabs on the display and

rotate it about 10° in a counterclockwise direction.

4. Remove the electronics module from the housing by loosening the two captive screws that

secure it to the housing. Then pull the module out of the housing far enough to gain

access to the cable connectors on the rear of the module.

5. Remove the four socket head screws securing the terminal block.

6. Disconnect the terminal block cable connector from the electronics module.

7. Remove the terminal block and the gasket under it.

8. Connect the new terminal block cable connector to the electronics module.

9. Install the new terminal block and new gasket and reinstall the four screws to 0.67 N⋅m

(6 in⋅lb) in several even increments.

10. Reinstall the electronics module (and digital display if applicable).

11. Reinstall the covers onto the housing by rotating them clockwise to seat the O-ring into the

housing and then continue to hand tighten until the each cover contacts the housing

metal-to-metal. If cover locks are present, lock the cover per the procedure described in

“Cover Locks” on page 17.

12. Turn on transmitter power source.

Product details:

PO972VA  FOXBORO Power module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
