FOXBORO X101AZ Controller module In Stock

1. For detailed information on balun use and installation, see “Using the Cable

Balun Module with Intelligent Transmitters” in System Equipment Installation

(B0193AC).

2. Cable balun used only when multiple loops are connected to a common power

supply. The FBM negative terminals connect directly to the minus (-) terminal of

the power supply. The balun system side negative (-) terminals (2, 4, 6, and 8)

connect to the power supply positive terminals when there are 4 (maximum)

power loops.

3. For hazardous environments, install an intrinsic safety barrier such as an MTL

787S+ between the balun wiring to limit the amount of energy in the wiring.

4. A user-supplied capacitor can be installed across the external power supply(ies)

to shunt AC power.

5. The external power supply can be redundant power supplies in parallel.

6. For this transmitter connection, use twisted-pair wiring inside a shielded cable

with the shield grounded at the Foxboro DCS end.

• Supported HART Instruments:

HART instruments compliant to Version 5, 6, or 7 of the HARTspecifications may be

used

• Interface:

8 individually isolated channels

• Communication to the Device:

Point-to-point, master/slave, asynchronous, half-duplex, at 1200 baud

• Detected Error Checking:

Parity on each byte, and one CRC check byte

• Speed:

2 messages per second

• Fastest Allowed ECB Block Period:

100 msec - However, we recommend that you see the Sizing Guidelines and Excel

Workbook appropriate for your Control Processor to determine the optimal loading

for a 100 msec Block Processing Cycle (BPC)

Product details：

FOXBORO X101AZ Controller module
