FOXBORO P0972ZQ

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

FOXBORO P0972ZQ IO module In Stock

• Loop Power Supply Protection:

The Compact FBM214b provides an individually isolated current limited loop supply

for each channel. All input loop supplies are limited by design to less than 37 mA.

• FBM Internal Power For Field Device:

Per channel isolated 24 V dc ±10% supply. Loop supply output impedance is 20 Ω

including the termination assembly.

• I/A Series®/Control Core Services:

Requires I/A Series software v8.2 to v8.8 or Control Core Services v9.0 or later.

• Isolation:

The individual channel inputs and loop supplies are galvanically isolated from each

other, ground and module logic. The module’s isolation is designed to withstand,

without damage, a common mode potential of 600 V ac applied for one minute

between the isolated input circuits and ground, or between a given channel and any

other channel.

• Supported HART Instruments:

HART instruments compliant to Version 5, 6, or 7 of the HARTspecifications may be

used

• Interface:

8 individually isolated channels

• Communication to the Device:

Point-to-point, master/slave, asynchronous, half-duplex, at 1200 baud

• Detected Error Checking:

Parity on each byte, and one CRC check byte

• Speed:

2 messages per second

• Fastest Allowed ECB Block Period:

100 msec - However, we recommend that you see the Sizing Guidelines and Excel

Workbook appropriate for your Control Processor to determine the optimal loading

for a 100 msec Block Processing Cycle (BPC)

Product details：

FOXBORO P0972ZQ IO module
