FOXBORO K014BDC

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

FOXBORO K014BDC Controller module In Stock

The IAP10-A Absolute Pressure Transmitters and the IGP10-A Gauge Pressure Transmitters measure

pressure by applying the pressure to a silicon strain gauge microsensor. This microsensor converts the

pressure to a change in resistance, and the resistance change is converted to a 4 to 20 mA signal proportional

to the pressure. This measurement signal is transmitted to remote receivers over the same

two wires that supply power to the transmitter.

For more detailed information on the principle of operation of the transmitter, refer to TI 037-096, available

 from Invensys Foxboro.

See Figure 1 for transmitter data plate contents. For a complete explanation of the Model Number

code, see the parts list. The firmware version is identified on the top line of the display when the transmitter

is powered.

(a) Refer to MI 020-369 for temperature limits with pressure seals.

(b) -40 and +75°C (-40 and +167°F) for transmitters with ATEX flameproof classification.

(c) Display updates are slowed and readability decreased below temperatures of -20°C (-4°F).

(d) 11 V dc with optional shorting block (AS code SB-11)

The transmitter can be mounted in any orientation. It can be directly mounted to the process

with either the direct connected or pipe mounted designs. The housing can be rotated up to

one full turn to any desired position for access to adjustments, display, or conduit connections.

See “Positioning the Housing” on page 15. The display (if present) can also be rotated in the

housing to any of four different positions at 90° increments.

Product details:

FOXBORO K014BDC Controller module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
