FOXBORO K0144SZ

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

FOXBORO K0144SZ Power module In Stock

The tank spud must be welded into a hole cut in the tank as follows:

1. Cut a hole into the process vessel.to accept the spud. The spud should fit snugly and

uniformly. The nominal diameter of the spud is: 3.73 inch (94.7 mm). To assure that the

seal is always covered by process fluid, the top of the hole should be below the minimum

measurement level.

2. Position the spud mounting ring so that it aligns as close as possible with the inside wall of

the tank and that the weep hole is at the bottom.

3. Tack weld the spud mounting ring to the outside of the tank in four places.

4. Weld the spud mounting ring to the inner surface of the tank per the following notes.

1. Spud is 316 stainless steel. Use compatible welding rod. Do not distort spud mounting

ring by using excessive heat.

2. Weld the spud mounting ring in sections as indicated in Figure 7.

3. After each section is welded, cool right away with water until the temperature is less

than 700°F (370°C) before welding the next section.

5. Grind the weld smooth so that the surface is free from irregularities where dirt can lodge.

6. Outer surface can be welded if desired after inner weld is completed.

Product details:

FOXBORO K0144SZ Power module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
