F0109AE-B FOXBORO IO module

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

F0109AE-B  FOXBORO IO module In Stock

Three and four wire RTDs are compensated up to 40 Ω for each lead. This is approximately equal

to 1220 m (4000 ft) of 20 gauge wire. The total resistance including the RTD and the two lead

wires is:

Therefore, if a platinum RTD is used to measure a maximum temperature of 1292 °F (700 °C),

the RTD resistance is 345 Ω and the maximum permissible lead wire resistance (for both leads

combined) is:

You may calculate the maximum permissible lead wire resistance for other RTD applications in a

similar manner.

For a single 2-wire RTD, the extension leads are in series with the sensing portion of the RTD, so

lead length should be minimized. If the distance between the transmitter and sensor is “long”,

change the RTD to a 3- or 4-wire RTD.

The “lead length” errors associated with two-wire RTDs are:

♦ Positive offset due to lead wire resistance

♦ Change in lead wire resistance due to ambient temperature changes is added to or

subtracted from the sensor reading

Product details:

F0109AE-B  FOXBORO IO module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
