823DP-13K1NM1 FOXBORO

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

823DP-13K1NM1  FOXBORO IO module In Stock

The display can be rotated within the housing to any of four positions at 90° increments. To do this,

refer to Figure 13 and perform the following:

1. Turn off power source to the transmitter.

2. Screw in the cover lock (if present) and remove the electronics compartment cover by

rotating it counterclockwise.

3. Remove the electronics module by unscrewing the two screws closest to the sides of the

transmitter and pulling out the module.

4. If turning the display 180°, turn and return the module to the housing by reversing Step 3.

5. If turning the display 90° in either direction:

a. Remove the two (2) plastic buttons (plugs) by pushing them out from the backside of

the module.

b. Unscrew the two (2) screws from the module and then rethread them back into the

module at 90° from their original position.

c. Insert the two (2) plastic buttons into the two open screw holes in the module. (To

order plastic buttons for earlier versions of the electronics modules or for replacement,

see appropriate Parts List listed in “Reference Documents” on page 1).

d. Return the module to the housing by reversing Step 3.

6. Reinstall the cover onto the housing by rotating it clockwise to seat the O-ring into the

housing and then continue to hand tighten until the cover contacts the housing metal-tometal.

If cover locks are present, align the serration in the cover with the lock and unscrew

it until it extends into the cover serration to prevent unwanted cover rotation.

7. Restore power to transmitter.

Product details:

823DP-13K1NM1  FOXBORO IO module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
