3A2-R2DP  FOXBORO IO module In Stock

• Input Resistance Including Termination Assembly:

◦ Externally Powered:

282 Ω

◦ Internally Powered:

302 Ω

• Loop Power Supply Protection:

The Compact 3A2-R2DP provides an individually isolated current limited loop supply

for each channel. All input loop supplies are limited by design to less than 37 mA.

• 3A2-R2DP Internal Power For Field Device:

Per channel isolated 24 V dc ±10% supply. Loop supply output impedance is 20 Ω

including the termination assembly.

• I/A Series®/Control Core Services:

Requires I/A Series software v8.2 to v8.8 or Control Core Services v9.0 or later.

• Isolation:

The individual channel inputs and loop supplies are galvanically isolated from each

other, ground and module logic. The module’s isolation is designed to withstand,

without damage, a common mode potential of 600 V ac applied for one minute

between the isolated input circuits and ground, or between a given channel and any

other channel.

Product details:

3A2-R2DP  FOXBORO IO module
