2AX-ALM-AS FOXBORO

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!

  We Can transport to the world!!!

*******************************************************

2AX-ALM-AS  FOXBORO IO module In Stock

1. A differential linkage measures difference between measurement pointer and setting

index positions. This error signal moves proportioning lever.

2. Proportioning lever pivots at its center on end of a flat spring.

3. This motion changes flapper nozzle relationship, causing relay to establish an output

pressure.

4. Output pressure is fed back to proportioning bellows, which acts through

proportioning lever to rebalance flapper nozzle.

5. Reset bellows and tank assembly are used when measurement must be maintained

exactly at control point (without “offset”).

6. Derivative tank assembly is used to improve system response to a slow process.

Make sure that measuring system is properly installed and operating.

Set control dial so that index points to desired control action (output either increases

or decreases with increasing measurement).

With latch in lowered position (as shown below), control dial cannot be accidentally

rotated to area of reverse control action.

Product details:

2AX-ALM-AS  FOXBORO IO module

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.

We have the same series of models in stock. If you don't find the model you need, please contact us and we will provide you with an official quotation！
