Emerson  DeltaV KJ3206X1-BA1 Power module In Stock

designed for 3 wire analog transmitters and can be used with

the AI 4-20mA HART CHARM. The ffeld power is supplied from

the injected power bus on the baseplate, but the power is not

removed from the ffeld device when the AI CHARM is removed

from the baseplate. There is a Green LED on the terminal block

that indicated power is supplied to the ffeld and the 2A fuse

also functions as a means to disconnect power from the ffeld

device. Although this terminal block was introduced in 2017,

it is backwards compatible to any version of DeltaV with

Electronic Marshalling.

Although any signal type can be installed in any location on the

CHARM baseplates, it is recommended that AC voltage circuits

be separated from low voltage signals to comply with safety

recommendations and to mitigate induced noise in the signals.

Standard Terminal blocks, Fused Injected Power terminal blocks

and Relay Output Blocks can be used on the same carrier,

typically, to allow the use of DO 24V DC isolated CHARMs

on higher wattage and 3-wire devices alongside of standard

24V DC instrumentation signals or relay contacts.

The Terminal Blocks contain keying posts that are automatically

set and locked to the unique position of the installed CHARM.

The keys prevent the insertion of an incorrect CHARM during

maintenance activities. They are shipped in a neutral position

and are set when a CHARM is inserted. If needed, the keys

can be manually reset to allow a channel to be re-tasked

for a different signal type.

Product details:

Emerson  DeltaV KJ3206X1-BA1 Power module
