BECKHOFF CU8800-0010

BECKHOFF CU8800-0010  Bus terminal module Bus coupler I/O terminal module

Product information：

Brand：BECKHOFF                            Model number：CU8800-0010

Lead Time：3-day working da        Country of origin: Germany

Price: Please contact us                   Product weight：0.09kg

HS: 8517623990

Product technial information：

The Beckhoff CU8800-0010 USB-Extender-Tx allows to extend the limits of USB cable length. Standard

USB cable are specified for cable length up to 5 meters. For some industrial applications there is need for

longer distances. This box can extend the distance up to 50 meters. This box sends the USB signals from

input port to the receiver box CU8850 or CU8860. Other outstanding features are:

• User-friendly installation via integrated DIN rail adapter

• No power supply needed – the box is supplied by USB (5V DC)

• 12 Mbit, and 1.5 Mbit support for compatibility to all USB1.1 standards

• Standard CAT5 network cable for extension

• Compact industrial design.

Proceed as follows to unpack the unit:

1. Remove packaging

2. Do not discard the original packaging. Keep it for future relocation

3. Check the delivery for completeness by comparing it with your order

4. Please keep the associated paperwork. It contains important information for handling the unit

5. Check the contents for visible shipping damage.

If you notice any shipping damage or inconsistencies between the contents and your order, you should

notify Beckhoff Service.

When connecting the cables to the CU8800-0010, proceed according to the following sequence:

• Switch off all the devices that are to be connected

• Disconnect all the devices that are to be connected from the power supply

• Connect all the cables between the CU8880-0010 and the devices that are to be connected

• Reconnect all devices to the power supply.

This configuration shows a CP69xx/ CP79xx Control Panel connected to the CU8800 extension box. The

maximal distance of extension is 51 meters: 1 meter of cable from the host computer to the CU8800

extension box; up to 50 meters extension cable to the Control Panel.
