1794-IA16 Allen-Bradley

1794-IA16 Allen-Bradley Input Module

Product information：

Brand：ALLEN-BRADLEY                        Model number：1794-IA16

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.1kg

HS: 8517623990

Product technial information：

For 1794-TB2, 1794-TB3, or 1794-TB3S – Connect individual input wiring to even-numbered terminals on the 0...15 row (A) as indicated in the Wiring Connections for 1794-

IA8 table.

For 1794-TBN – Connect individual input wiring to numbered terminals on the 16...33 row (B) as indicated in the Wiring Connections for 1794-IA8 table.

For 1794-TB2 – Connect the associated 120V AC power lead (L1) of the input device to the corresponding odd-numbered terminals on the 0...15 row A for each input as

indicated in the Wiring Connections for 1794-IA8 table. Odd-numbered terminals on row A are internally connected to 120V AC L1.

For 1794-TB3 or 1794-TB3S – Connect the associated 120V AC power lead (L1) of the input device to the corresponding odd-numbered terminals on the 34...51 row (C) or

to the corresponding terminal on row (C) for each input as indicated in the Wiring Connections for 1794-IA8 table. Odd-numbered terminals on row (A) and the terminals of

row (C) are internally connected to 120V AC power L1.

For 1794-TBN – Connect the associated 120V AC power lead (L1) of the input device to the corresponding odd-numbered terminal on the 34...51 row (C) for each input as

indicated in the Wiring Connections for 1794-IA8 table. The 120V AC power terminals of row (C) are internally connected together.

2. Connect 120V AC power (L1) to terminal 34 on the 34...51 row (C).

3. Connect 120V AC common (L2) to terminal 16 on the 16...33 row (B).

4. If daisy chaining power to the next terminal base, connect a jumper from terminal 51 (+120V AC L1) on this terminal base to terminal 34 on the next terminal base.

5. If continuing AC common to the next terminal base, connect a jumper from terminal 33 (120V common L2) on this terminal base to terminal 16 on the next terminal base.
