1794-0E4 Allen-Bradley FLEX I/O Analog Modules

1794-0E4 Allen-Bradley FLEX I/O Analog Modules

Product information：

Brand：Allen-Bradley                              Model number：1794-0E4

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: United States

Price: Please contact us                   Product weight：0.100kg

HS: 8517623990

Product technial information：

1. Remove the cover plug (if used) in the male connector of the unit

to which you are connecting this terminal base unit.

2. Check to make sure that the 16 pins in the male connector on the

adjacent device are straight and in line so that the mating female

connector on this terminal base unit will mate correctly.

3. Position the terminal base on the 35 x 7.5mm DIN rail A (A-B pt.

no. 199-DR1; 46277-3; EN 50022) at a slight angle with hook B

on the left side of the terminal base hooked into the right side of

the unit on the left.

4. Make certain that the female flexbus connector C is fully

retracted into the base unit.

5. Rotate the terminal base onto the DIN rail with the top of the rail

hooked under the lip on the rear of the terminal base. Use caution

to make sure that the female flexbus connector does not strike

any of the pins in the mating male connector.

6. Press the terminal base down onto the DIN rail until flush. The

locking tab D will snap into position and lock the terminal base to

the DIN rail.

7. If the terminal base does not lock in place, use a screwdriver or

similar device to move the locking tab down, press the terminal

base flush with the DIN rail and release the locking tab to lock

the base in place.

8. Gently push the female flexbus connector C into the adjacent

terminal base or adapter female connector to complete the flexbus

connections.

9. Repeat the above steps to install the next terminal base.

Delivery information：

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Transport: In Stock Ready for Shipment via DHL, TNT, FEDEX, UPS, ARAMEX and etc

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!!  We Can transport to the world!!!

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.
