1769-SDN Allen-Bradley DeviceNet Scanner Communication Module DeviceNet

BENEFITS:(I WILL GIVE YOU A REPLY IMMEDIATELY)

Quantity available: 1

The colour：100% New Original Genuine Products

Warranty: 12 months.

Lead time: 3 days.

Payment: T/T 、 Western Union.

Transport: In Stock Ready for Shipment via DHL, TNT, FEDEX, UPS, ARAMEX and etc

Service：Professional Sales Provide 24hours/7 day Online Services

Welcome, thank you for your trust, The seller has more than $1526000 worth of industrial control products inventory.hope we can help you solve your problem!!! We Can transport to the world!!!

Inquire Now +

PRODUCT DETAIL

CompactLogix Communication Modules Specifications

Product information：

Brand：Allen-Bradley Model number：1769-SDN

Colour：new Warranty: 12 month

Lead Time：3-day working da Country of origin: USA

Price: Please contact us Product weight：0.09kg

Product technial information：

*Communication Connections

A ControlLogix system uses connections to establish communication links between devices. The types of connections

include:

• controller-to-local I/O modules or local communication modules.

• controller-to-remote I/O or remote communication modules.

• controller-to-remote I/O (rack-optimized) modules.

• produced and consumed tags.

• messages.

• controller access by RSLogix 5000 programming software.

• controller access by RSLinx software for HMI or other applications.

You indirectly determine the number of connections the controller uses by configuring the controller to communicate with

other devices in the system. The limit of connections may ultimately reside in the communication module you use for the

connection. If a message path routes through a communication module, the connection related to the message also counts

towards the connection limit of that communication module.

Table 7 - Technical Specifications - 1769 DeviceNet Modules

Attribute	1769-SDN(1)	1769-ADN
DeviceNet communication rate	125 Kbps (500 m max) 250 Kbps (250 m max) 500 Kbps (100 m max)
Number of nodes, max	64	30
Current draw @ 5V DC	440 mA	Series A 450 mA Series B 500 mA
Current draw @ 24V DC	0 mA
DeviceNet current range	11…25V DC
DeviceNet current draw	110 mA @ 24V DC Class 2/SELV	90 mA @ 24V DC Class 2/SELV
Power dissipation	4.7 W	4.7 W
Isolation voltage	30V (continuous), basic insulation type, DeviceNet to backplane Type tested at 710V DC for 60 s
Weight, approx.	0.280 kg (0.61 lb)
Dimensions (HxWxD), approx.	118 x 50 x 87 mm (4.65 x 1.97 x 3.43 in.)
Slot width	1
Module location	DIN rail or panel mount
Mounting screw torque	1.16 NOm (10 lbOin) - use M4 or #8 screws
Power supply distance rating	4 modules	Series A 4 modules Series B 5 modules
Ports	1 DeviceNet open-style 5-pin linear plug
DeviceNet connector torque	0.56…0.79 N•m (5…7 lb•in)
Wire size	802.3 compliant shielded or unshielded twisted pair
Wire category	2 - on communication ports(2)
North American Temperature Code	T3C	T4A
Enclosure type rating	None (open-style)

Delivery information：

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service

Contact information：

Contact person：Luna Chen

Email Address:：sales6@saulplc.com

WhatApp： +86 13358378970

We look forward to your inquiry and will get back to you as soon as possible.
