ABB REF615

ABB REF615 Feeder Protection and Control

Product information：

Brand：ABB                             Model number：REF615

Condition：new                              Warranty: 12 month

Lead Time：3-day working da        Country of origin: Sweden

Price: Please contact us                   Product weight：3.87kg

HS: 8517623990

Product technial information：

ABB REF615 Detailed Product Description

Product Overview

The ABB REF615 is a dedicated feeder protection and control relay designed for the protection, control, measurement, and supervision of utility and industrial power distribution systems. It's part of ABB's Relion® family and offers a comprehensive suite of features for reliable and efficient power system operation.

Key Features and Benefits

• Comprehensive Protection:

• Directional and non-directional overcurrent and earth-fault protection

• Voltage, frequency, and power-based protection and measurement


  1. new.abb.com

  new.abb.com

• Extensive earth-fault protection with unique multi-frequency admittance-based protection

• Optional advanced and fast fault location

• Arc protection and high-speed outputs

• Versatility:

• Suitable for radial, looped, and meshed distribution networks

• Can be used with or without distributed power generation

• Advanced Communication:

• Supports IEC 61850 Editions 1 and 2

• HSR and PRP for high availability

• GOOSE messaging

• IEC 61850-9-2 LE for reduced wiring

• Reliability and Security:

• Compact and withdrawable design

• Engineered for IEC 61850 interoperability

• User-Friendliness:

• Large graphical display

• Customizable SLDs

• Easy-to-use web-based HMI

• Other Features:

• Underground, overhead cable fault detection (CFD)

• High-impedance (HIZ) fault detection

• Arc flash detection (AFD)

• Ring-lug terminals


  1. new.abb.com

  new.abb.com

• Flexible three-phase multi-shot auto-reclose function

Technical Specifications

• Mounting: Drawout design

• Communication: IEC 61850, GOOSE, HSR, PRP, Modbus

• Inputs: Current, voltage, frequency, temperature

• Outputs: Trip, alarm, control

• Dimensions: Refer to the product datasheet for specific dimensions

Applications

• Utility substations

• Industrial power systems

• Overhead and underground distribution networks

• Renewable energy integration

Precautions

• Installation: Follow the manufacturer's installation instructions carefully.

• Configuration: Ensure correct configuration of the relay to match the specific application.

• Maintenance: Perform regular maintenance as recommended by the manufacturer.

• Environment: The relay should be installed in a suitable environment to avoid damage.
